/ Eboard — 10 mm Non‑Combustible and FRL Panel
Eboard is a 10 mm non‑combustible panel designed for façades, boundary walls and modular systems. It can be painted, rendered or paired with the Stonewood cladding range to achieve modern architectural finishes while supporting compliant wall system performance and FRL rating.
/ Key Benefits
Eboard™ 10mm panel that has been designed to assist to offer a decorative solution to a fire rated wall.
- 10 mm non‑combustible panel
- Lightweight and easy to cut with standard tools
- Ideal for decorative façades and modular builds
- Suitable as a finish layer for boundary‑wall systems
- Can be painted or combined with Stonewood
- Supports compliant detailing across multiple applications
CHECK OUT OUR STONEWOOD® CLADDING!
Cement panels wood inspired cladding panels
designed for ease of install and savings
/ Applications
Eboard is suited to:
- Decorative façades and architectural finishes
- Modular and prefabricated building systems
- Boundary wall finish layers (per system specification)
- Internal or external decorative applications (as per guide)
- Projects using mixed materials requiring non‑combustible panels
/ Finishes
- Paint-ready surface
- Can be combined with Stonewood for wood‑look or contemporary façades
- Suitable for a secondary finish layer where a clean, uniform surface is required.
/ Installation
- Cut and drill with standard blades and bits
- Lightweight and easy to handle on site
- Fixed using common façade fastening methods
- Clear installation guide outlines fixings, joints and finish layers
CBMA Eboard is a multiuse non combustible panel. Designed to provide a simple and effective solution for many applications on site.
Townhouse | Apartments | Cladding | Non-combustible
Properties |
Specification |
Manufacturing Tolerance |
Standard |
|---|---|---|---|
| Dimensions – Overall Coverage |
2400mm x 1200mm x 10mm 2700mm x 1200mm x 10mm |
Width / Length: +/- 2mm Depth: +1.5mm -0mm |
AS2908.2 |
| Profile | Square edge | ||
| Characteristics | Pink in colour | ||
| Panel Layout | Horizontal and/or Vertical | ||
| Weight (Approx) | 12.8kg/m2 | ||
Zerobound has been tested and certified by independent industry professionals including NATA accredited laboratories. Zerobound has been accredited with CodeMark certification.
Properties |
Result |
Standard |
|---|---|---|
| Combustibility | Pass as non-combustible | AS1530.1 |
| Weatherproofing | Pass | AS4040.2 |
| Wind Classifications | N1, N2, N3 | AS4055 |
| Thermal | Rt(summer) 2.8m2K/W and Rt(winter)3.1K/W (R2.7 batts) | AS/NZS4859.1 |
/ more products
Can Eboard be used externally?
Yes, Eboard can be used in external applications when installed according to the system and finish requirements in the installation guide.
What finish options can be applied to Eboard?
Eboard can be painted or combined with Stonewood to achieve a range of architectural façade looks.
Does Eboard require special tools?
No. Eboard can be cut and drilled using standard saw blades and drill bits.
Is Eboard non‑combustible?
Yes. Eboard is a non‑combustible decorative panel, suitable for use in compliant façade and boundary‑wall systems.
